SQL Data Types – Understanding The Differences

Common SQL Data Types

Before diving into the many different data types available in SQL, let’s start with a list of the various options available to SQL data types. In SQL (Structured Query Language), the following are commonly used data types:

1. Numeric Types:

   • INT (integer): Signed integer values.
   • BIGINT: Large signed integer values.
   • SMALLINT: Small signed integer values.
   • DECIMAL(p, s): Fixed precision and scale numeric values.
   • NUMERIC(p, s): Same as DECIMAL.
   • FLOAT(p): Approximate numeric values with a floating decimal point.
   • REAL: Single-precision floating-point values.
   • DOUBLE PRECISION: Double-precision floating-point values.

2. Character/String Types:

   • CHAR(n): Fixed-length character strings with a maximum length of n.
   • VARCHAR(n): Variable-length character strings with a maximum length of n.
   • TEXT: Variable-length character strings with a maximum length of 2^31-1 (2,147,483,647) characters.

3. Date and Time Types:

   • DATE: Date values (year, month, and day).
   • TIME: Time values (hour, minute, and second).
   • TIMESTAMP: Date and time values.

4. Boolean Type:

   • BOOLEAN: Represents the truth values TRUE or FALSE.

5. Binary Types:

   • BINARY(n): Fixed-length binary strings with a maximum length of n.
   • VARBINARY(n): Variable-length binary strings with a maximum length of n.
   • BLOB: Binary large object with a maximum length of 2^31-1 (2,147,483,647) bytes.

6. Other Types:

   • UUID: Universally unique identifier.
   • XML: Stores XML data.
   • JSON: Stores JSON (JavaScript Object Notation) data.

Note that the specific data types available may vary depending on the database management system (DBMS) you are using, as different DBMSs might support additional or proprietary data types.

Why Have Different SQL Data Types?

In SQL (Structured Query Language), different data types are used to specify the type of data that can be stored in a particular column of a table. The choice of data type for each column is important for several reasons:

Data Integrity: By using appropriate data types, you can ensure that the data stored in the column is consistent and valid. For example, if you have a column that stores dates, using the DATE data type will enforce the integrity of the data, allowing only valid dates to be stored in that column.

Storage Efficiency: Different data types have different storage requirements. By choosing the appropriate data type, you can optimize storage space. For example, using an INTEGER data type for a column that stores whole numbers will require less storage space compared to using a VARCHAR data type.

Data Validation: Data types allow you to validate the input and ensure that it adheres to certain constraints. For instance, if you have a column that should only contain numeric values, using a numeric data type (e.g., INTEGER, DECIMAL) will automatically reject non-numeric inputs.

Query Performance: The data type used in a column can impact the performance of SQL queries. Properly chosen data types can improve query execution speed and efficiency. For example, using appropriate data types for indexing columns can speed up search operations.

Data Manipulation: Different data types provide different functionalities and operations. For example, using a string data type (e.g., VARCHAR) allows you to perform string manipulation operations like concatenation, substring extraction, and pattern matching.

Compatibility: SQL databases often need to interact with other systems or programming languages. Using standard data types ensures compatibility and seamless data exchange between different systems.

Overall, using different data types in SQL allows for precise data representation, efficient storage, data integrity, and optimal query performance, leading to a well-structured and reliable database system.

Advance Your IT Career
with ITU Online's Training Subscriptions

Unlock the full potential of your IT career with ITU Online’s comprehensive online training subscriptions. Our expert-led courses will help you stay ahead of the curve in today’s fast-paced tech industry.

Numerical SQL Data Type Options

As we listed above, there are 8 different common data types used to store numerical data values.  Let’s dive into each one and provide an example of when each type is best suited for use.

The INT (integer) Numerical SQL Data Type

In SQL, the INT (integer) data type is used to store whole numbers without decimal places. An integer is a whole number that can be either positive, negative, or zero. It does not include fractional or decimal parts. Integers are part of the number system and are commonly used in mathematics and computer programming. They are represented without a decimal point or a fraction line.

Examples of integers include -3, 0, 7, and 100. It is commonly used for representing numerical values, such as counts, identifiers, or indices. The exact range of values that can be stored in an INT column depends on the specific database management system (DBMS) being used.

Here’s an example of creating a table in SQL with an INT column and inserting data into it:

-- Creating a table with an INT column
CREATE TABLE Employees ( EmployeeID INT, FirstName VARCHAR(50), LastName VARCHAR(50), Age INT );

-- Inserting data into the table
INSERT INTO Employees (EmployeeID, FirstName, LastName, Age) VALUES (1, 'John', 'Doe', 30);
INSERT INTO Employees (EmployeeID, FirstName, LastName, Age) VALUES (2, 'Jane', 'Smith', 28);
INSERT INTO Employees (EmployeeID, FirstName, LastName, Age) VALUES (3, 'Robert', 'Johnson', 35);

In the above example, we created a table named “Employees” with four columns: “EmployeeID” of type INT, “FirstName” of type VARCHAR (variable-length character string), “LastName” of type VARCHAR, and “Age” of type INT.

We then inserted three rows of data into the table using the INSERT INTO statement. The values provided for the “EmployeeID” and “Age” columns are integers.

The BIGINT Numerical SQL Data Type

In SQL, the BIGINT data type is used to store large integer values that exceed the range of the standard INTEGER data type. It is typically used when you need to store very large whole numbers, such as unique identifiers, counters, or timestamps that require a larger number of digits.

The range of values that can be stored in a BIGINT varies depending on the database system, but it is generally a signed 64-bit integer, allowing values from -9,223,372,036,854,775,808 to 9,223,372,036,854,775,807. This gives you a wide range of possible values to work with.

Here’s an example of creating a table with a column of the BIGINT data type in SQL:

<code>CREATE TABLE myTable (
    id BIGINT,
    name VARCHAR(50)
);<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-5); font-weight: inherit;"></span>

In the above example, a table named “myTable” is created with two columns. The first column is named “id” and has the BIGINT data type, while the second column is named “name” and has the VARCHAR data type with a maximum length of 50 characters.

You can then insert values into the table, specifying the BIGINT value for the “id” column:

<code>INSERT INTO myTable (id, name) VALUES (1234567890123456789, 'John Doe');

In this case, a row is inserted into the “myTable” table with the value 1234567890123456789 in the “id” column and ‘John Doe’ in the “name” column.

It’s important to note that not all database systems support the BIGINT data type. However, most popular database systems such as MySQL, PostgreSQL, and Microsoft SQL Server provide support for it.

The SMALLINT Numerical SQL Data Type

In SQL, the SMALLINT data type is used to represent a small integer value within a specified range. It is typically used when you need to store numbers that fall within a smaller range compared to the INT data type, thus conserving storage space.

The SMALLINT data type is typically represented as a 2-byte signed integer, allowing for values from -32,768 to 32,767. The exact range may vary depending on the database system you are using.

Here’s an example of creating a table with a column defined as SMALLINT:

<code>CREATE TABLE Employee (
    EmployeeID INT,
    Name VARCHAR(50),
    Age SMALLINT
);<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-5); font-weight: inherit;"></span>

In this example, we have a table named “Employee” with three columns: “EmployeeID” of type INT, “Name” of type VARCHAR(50), and “Age” of type SMALLINT.

You can insert data into the table like this:

<code>INSERT INTO Employee (EmployeeID, Name, Age)
VALUES (1, 'John Doe', 25);<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-5); font-weight: inherit;"></span>

Here, we insert a row with an EmployeeID of 1, Name of ‘John Doe’, and Age of 25.

Note that you can perform various operations and calculations on the SMALLINT data type, just like with other numeric data types in SQL.

The DECIMAL(p, s) and NUMERIC(p, s) SQL Numerical Data Type

In SQL, the DECIMAL(p, s) and NUMERIC(p, s) data type is used to store decimal numbers with a specified precision and scale. The precision (p) represents the total number of digits that can be stored, while the scale (s) specifies the number of digits that can be stored after the decimal point. This data type is commonly used for financial and monetary values that require exact decimal calculations.

Here’s an example of how to use the DECIMAL data type in SQL:

<code>Create a table with a DECIMAL column
CREATE TABLE Sales (
    SaleID INT PRIMARY KEY,
    Amount DECIMAL(10, 2) -- Precision: 10, Scale: 2
);

-- Insert values into the Sales table
INSERT INTO Sales (SaleID, Amount)
VALUES (1, 1250.75),
       (2, 500.50),
       (3, 150.00);

-- Retrieve all sales with their amounts
SELECT *
FROM Sales;

In the example above, we create a table called “Sales” with two columns: “SaleID” of type INT and “Amount” of type DECIMAL(10, 2). This means the “Amount” column can store numbers with a total of 10 digits, including 2 decimal places. We then insert three sales records with their respective amounts. Finally, we retrieve all the sales records from the table.

The resulting output would be:

<code>SaleID | Amount
-------|-------
1      | 1250.75
2      | 500.50
3      | 150.00

The DECIMAL data type ensures that the precision and scale are maintained, allowing for precise calculations. For example, if you were to perform calculations like addition or multiplication on the “Amount” column, the result would also be a DECIMAL value with the specified precision and scale.

The FLOAT(p) Numerical SQL Data Type

In SQL, the FLOAT(p) data type is used to store floating-point numbers with a specified precision. The “p” parameter represents the precision, which indicates the maximum number of digits that can be stored in the number. The actual storage size of a FLOAT(p) value depends on the system, but it typically ranges from 4 to 8 bytes.

Here’s an example of creating a table with a column defined as FLOAT(4) in SQL:

<code>CREATE TABLE MyTable (
  ID INT,
  Value FLOAT(4)
);<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-5); font-weight: inherit;"></span>

In this example, the “Value” column is defined as FLOAT(4), which means it can store a floating-point number with a precision of up to 4 digits. Here are some possible values that can be stored in the “Value” column:

• 12.34
• 1.234
• 123.4

Note that if you attempt to insert a value with more than 4 digits of precision, it may be rounded or truncated to fit within the specified precision. For example, if you try to insert a value of 12345.678 into the “Value” column, it may be stored as 1234 or 1234.6, depending on the rounding rules of the DBMS.

The REAL Numerical SQL Data Type

In SQL, the REAL data type is used to represent single-precision floating-point numbers. It is commonly used for storing decimal values with a moderate range of precision. The REAL type typically requires 4 bytes of storage and adheres to the IEEE 754 floating-point standard.

Here’s an example of using the REAL data type in a table called “Products” to store the prices of various products:

<code>CREATE TABLE Products (
  ProductID INT,
  ProductName VARCHAR(50),
  Price REAL
);

In this example, the “Products” table has three columns: “ProductID” of type INT (integer), “ProductName” of type VARCHAR(50) (variable-length string), and “Price” of type REAL.

To insert data into the table, you can use an SQL INSERT statement:

<code>INSERT INTO Products (ProductID, ProductName, Price)
VALUES (1, 'Product A', 9.99),
       (2, 'Product B', 19.95),
       (3, 'Product C', 4.75);

In this case, we are inserting three rows into the “Products” table, specifying the values for the “ProductID,” “ProductName,” and “Price” columns. The prices are represented using the REAL data type.

It’s important to note that floating-point numbers (including REAL) have limited precision and can introduce rounding errors when performing calculations. If high precision is required, it’s advisable to use a data type like DECIMAL or NUMERIC that supports fixed-point arithmetic with configurable precision and scale.

The DOUBLE PRECISION Numerical SQL Data Type

In SQL, the DOUBLE PRECISION data type is used to store floating-point numbers with high precision. It is also known as a double or a double-precision floating-point number. The DOUBLE PRECISION data type allows for a larger range of values and more decimal places compared to the FLOAT data type.

The precision of a DOUBLE PRECISION value depends on the database system, but it typically provides 15 to 17 significant digits. The actual storage size may vary, but it is usually 8 bytes.

Here’s an example of how you can create a table with a column of DOUBLE PRECISION data type in SQL:

<code>CREATE TABLE MyTable (
  id INT,
  value DOUBLE PRECISION
);

In this example, a table named “MyTable” is created with two columns: “id” of type INT (integer) and “value” of type DOUBLE PRECISION. The “value” column can store floating-point numbers with high precision.

You can insert data into this table using an SQL INSERT statement, like this:

<code>INSERT INTO MyTable (id, value) VALUES (1, 3.14159);
INSERT INTO MyTable (id, value) VALUES (2, 2.71828);<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-3); font-weight: inherit;"></span>

In the above example, two rows are inserted into the “MyTable” table. The first row has an “id” of 1 and a “value” of 3.14159, which is a floating-point number representing pi. The second row has an “id” of 2 and a “value” of 2.71828, which is a floating-point number representing the mathematical constant e.

Remember to adjust the precision and scale of the DOUBLE PRECISION data type based on your specific database system and requirements.

Character/String SQL Data Type Options

The CHAR(n) SQL Data Type

In SQL, the CHAR(n) data type represents a fixed-length character string of length ‘n’. It is commonly used to store strings with a predetermined and constant length. The ‘n’ parameter specifies the maximum number of characters that can be stored in the column. If a string shorter than ‘n’ is stored, the remaining characters are padded with spaces to fill the fixed length.

Here are some examples to illustrate the usage of the CHAR(n) data type:

Example 1: Consider a table called “Employees” with a column “EmployeeCode” defined as CHAR(5). It can store employee codes that are always five characters long. If an employee code is shorter than five characters, it will be padded with spaces.

<code>CREATE TABLE Employees (
    EmployeeCode CHAR(5),
    Name VARCHAR(50),
    -- other columns
);<span style="background-color: initial; font-family: inherit; font-size: inherit; font-weight: inherit;"></span>

Example 2: Suppose you have a table called “Products” with a column “ProductCode” defined as CHAR(10). It can store product codes that are always ten characters long. If a product code is shorter than ten characters, it will be padded with spaces.

<code>CREATE TABLE Products (
    ProductCode CHAR(10),
    Name VARCHAR(50),
    -- other columns
);<span style="background-color: initial; font-family: inherit; font-size: inherit; font-weight: inherit;"></span>

Example 3: In a table called “Countries,” you might have a column “CountryCode” defined as CHAR(3) to store country codes. The country codes are three characters long, such as “USA” for the United States or “GBR” for Great Britain.

<code>CREATE TABLE Countries (
    CountryCode CHAR(3),
    Name VARCHAR(50),
    -- other columns
);

In these examples, the CHAR(n) data type ensures that the stored values are always of a fixed length, which can be useful for maintaining consistent data structures and facilitating comparisons and sorting operations. However, it’s important to note that CHAR(n) columns use the entire length ‘n’ for each stored value, even if it is shorter than ‘n’, which can consume more storage space compared to variable-length data types like VARCHAR.

The VARCHAR(n) SQL Data Type

In SQL, the VARCHAR(n) data type is used to store variable-length character strings. The “n” represents the maximum number of characters that can be stored in the VARCHAR column. The actual length of the stored value can be less than or equal to “n” characters.

Here’s an example to illustrate the usage of VARCHAR(n):

Let’s say we have a table called “Employees” with the following structure:

<code>CREATE TABLE Employees (
    ID INT,
    FirstName VARCHAR(50),
    LastName VARCHAR(50),
    Email VARCHAR(100)
);<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-3); font-weight: inherit;"></span>

In this example, the “FirstName” and “LastName” columns are defined as VARCHAR(50), meaning they can store strings with a maximum length of 50 characters each. The “Email” column is defined as VARCHAR(100), allowing a maximum length of 100 characters.

We can then insert some data into the table:

<code>INSERT INTO Employees (ID, FirstName, LastName, Email)
VALUES (1, 'John', 'Doe', 'john.doe@example.com');

INSERT INTO Employees (ID, FirstName, LastName, Email)
VALUES (2, 'Jane', 'Smith', 'jane.smith@example.com');<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-3); font-weight: inherit;"></span>

In this example, we insert two rows into the “Employees” table. The first row has a first name of ‘John’, a last name of ‘Doe’, and an email address of ‘john.doe@example.com’. The second row has a first name of ‘Jane’, a last name of ‘Smith’, and an email address of ‘jane.smith@example.com’.

The VARCHAR data type allows flexibility in storing variable-length character data, making it suitable for columns where the length of the data may vary. By specifying the maximum length for VARCHAR columns, you can enforce data integrity constraints and optimize storage space.

The TEXT SQL Data Type

In SQL, the TEXT data type is used to store large amounts of alphanumeric character data. It is designed to hold variable-length strings that can be extremely long, ranging from a few characters to several gigabytes in size. TEXT data type is commonly used to store documents, articles, log files, or any other large textual data.

Here’s an example of creating a table with a TEXT column in SQL:

<code>CREATE TABLE documents (
    id INT,
    content TEXT
);

In this example, we have a table named “documents” with two columns: “id” of type INT and “content” of type TEXT.

To insert data into the “content” column, you can use an INSERT statement like this:

<code>INSERT INTO documents (id, content) VALUES (1, 'This is a sample document.');<span style="background-color: initial; font-family: inherit; font-size: inherit; color: var(--ast-global-color-3); font-weight: inherit;"></span>

Remember that the actual storage limit for TEXT data can vary depending on the specific database system you are using.

Date and Time Data Type Options

The DATE SQL Data Type

In SQL, the DATE data type is used to store dates without any time information. It represents a specific calendar date, including the year, month, and day, but excludes any time components such as hours, minutes, and seconds. The DATE data type is supported by most relational database management systems (RDBMS), including MySQL, Oracle, SQL Server, and PostgreSQL.

Here’s an example of creating a table with a DATE column in SQL:

<code>CREATE TABLE my_table (
  id INT,
  event_date DATE
);

In the above example, a table named “my_table” is created with two columns: “id” of type INT and “event_date” of type DATE. The “event_date” column will store dates in the format YYYY-MM-DD.

To insert data into the table, you can use the INSERT INTO statement along with the appropriate date format:

<code>INSERT INTO my_table (id, event_date)
VALUES (1, '2023-05-27');

In this example, a row is inserted into the “my_table” table with an ID of 1 and an “event_date” of ‘2023-05-27’, which represents May 27, 2023.

You can also retrieve data based on date conditions using SQL queries. Here’s an example of a SELECT statement that fetches records where the “event_date” is after a specific date:

<code>SELECT * FROM my_table
WHERE event_date > '2023-01-01';

This query will return all the rows from the “my_table” table where the “event_date” is later than January 1, 2023.

The DATE data type allows you to perform various date-related operations and calculations in SQL, such as date arithmetic, date comparisons, and date formatting.

The TIME SQL Data Type

In SQL, the TIME data type is used to store time values without a date component. It represents a specific time of day in a 24-hour format (hours, minutes, seconds) or a fraction of a second.

The standard syntax for declaring a TIME column in SQL is as follows:

<code>CREATE TABLE table_name (
    column_name TIME
);

Here’s an example to illustrate the usage of the TIME data type:

<code>CREATE TABLE events (
    event_id INT PRIMARY KEY,
    event_name VARCHAR(50),
    event_time TIME
);

In this example, we have a table called “events” with three columns: “event_id,” “event_name,” and “event_time.” The “event_time” column is defined as the TIME data type.

Let’s insert some sample data into the “events” table:

<code>INSERT INTO events (event_id, event_name, event_time)
VALUES
    (1, 'Meeting', '09:30:00'),
    (2, 'Lunch Break', '12:00:00'),
    (3, 'Presentation', '15:45:30');<span style="background-color: initial; font-family: inherit; font-size: inherit; font-weight: inherit;"></span>

In the above INSERT statement, we provided specific time values for each event. The time values are enclosed in single quotes and follow the format ‘HH:MI:SS’ (hours, minutes, seconds). The first event occurs at 09:30:00, the second event at 12:00:00, and the third event at 15:45:30.

To retrieve the event details from the “events” table, you can use a SELECT statement:

<code>SELECT * FROM events;

The result would be:

<code>event_id | event_name     | event_time
---------+----------------+------------
1        | Meeting        | 09:30:00
2        | Lunch Break    | 12:00:00
3        | Presentation   | 15:45:30

The TIME data type allows you to perform various operations, such as comparing time values, extracting specific components (hours, minutes, seconds), and performing calculations based on time durations.

Note that the actual syntax and available features may vary slightly depending on the specific SQL database system you are using, as there can be some vendor-specific differences in how the TIME data type is implemented.

The TIMESTAMP SQL Data Type

In SQL, the TIMESTAMP data type is used to store date and time values. It represents a specific point in time, typically with millisecond precision. The exact behavior of the TIMESTAMP data type can vary depending on the specific database management system (DBMS) you are using.

Here’s an example of how the TIMESTAMP data type can be used in SQL:

Let’s say we have a table called “Orders” with the following columns:

<code>CREATE TABLE Orders (
    OrderID INT PRIMARY KEY,
    OrderDate TIMESTAMP,
    CustomerID INT,
    TotalAmount DECIMAL(10, 2)
);

In this example, the “OrderDate” column is defined as a TIMESTAMP data type. It will store the date and time when an order was placed.

To insert a new row into the “Orders” table, including the order date, you can use the following SQL statement:

<code>INSERT INTO Orders (OrderID, OrderDate, CustomerID, TotalAmount)
VALUES (1, '2023-05-27 10:30:45', 1234, 99.99);

Here, we explicitly specify the order date as a string in the format ‘YYYY-MM-DD HH:MI:SS’. The DBMS will internally convert this string to a TIMESTAMP value and store it in the “OrderDate” column.

You can also retrieve and query TIMESTAMP values. For example, to select all orders placed after a certain date, you can use the following SQL query:

<code>SELECT *
FROM Orders
WHERE OrderDate > '2023-01-01';

This query will retrieve all rows from the “Orders” table where the “OrderDate” is greater than ‘2023-01-01’.

Note that the exact syntax and capabilities of the TIMESTAMP data type may vary depending on the specific DBMS you are using. It’s always a good idea to consult the documentation of your chosen database system for detailed information on its TIMESTAMP data type implementation.

The BOOLEAN SQL Data Type

It’s Only True or False

In SQL, the BOOLEAN data type represents a logical value that can be either true or false. It is used to store and manipulate binary (true/false) information in a database. The BOOLEAN data type is not supported in all database management systems, but many popular ones, such as PostgreSQL and MySQL, include it.

Here’s an example of how the BOOLEAN data type can be used in a SQL table:

Let’s say we have a table named “Employees” with the following columns:

<code>CREATE TABLE Employees (
    ID INT,
    Name VARCHAR(50),
    Active BOOLEAN
);

In this example, the “Active” column is defined as a BOOLEAN data type. It can store values such as true or false to indicate whether an employee is currently active or not.

To insert data into the table, we can use the INSERT statement:

<code>INSERT INTO Employees (ID, Name, Active)
VALUES (1, 'John Doe', true);

INSERT INTO Employees (ID, Name, Active)
VALUES (2, 'Jane Smith', false);

In the above example, we inserted two rows into the “Employees” table. The first row has an ID of 1, a name of “John Doe,” and the Active column is set to true. The second row has an ID of 2, a name of “Jane Smith,” and the Active column is set to false.

You can also perform various operations on BOOLEAN values using SQL. For instance, you can use logical operators like AND, OR, and NOT to evaluate or manipulate BOOLEAN values in queries.

Here’s an example of a SELECT statement that retrieves active employees from the “Employees” table:

<code>SELECT *
FROM Employees
WHERE Active = true;

This query will return all the rows from the “Employees” table where the Active column has a value of true, indicating the active employees.

That’s a basic explanation of the BOOLEAN data type in SQL, along with an example of how it can be used in a table. Remember that the actual implementation and syntax may vary depending on the specific database management system you are using.

The BINARY SQL Data Types

The BINARY(n) Data Type

In SQL, the BINARY(n) data type represents a fixed-length binary string of length ‘n’ bytes. It is commonly used to store binary data such as images, audio files, or other binary objects.

The ‘n’ in BINARY(n) specifies the maximum length of the binary string, which can range from 1 to 8,000 bytes, depending on the database system. The actual storage size of the BINARY(n) column will always be ‘n’ bytes, regardless of the data it contains. If a binary value shorter than ‘n’ bytes is stored, it will be padded with trailing zeros to match the specified length.

Here’s an example of creating a table with a BINARY(n) column in SQL:

<code>CREATE TABLE BinaryData (
    ID INT PRIMARY KEY,
    Data BINARY(10)
);

In the example above, a table named “BinaryData” is created with two columns. The “ID” column is an integer and serves as the primary key, while the “Data” column is of type BINARY(10), which means it can store binary data of up to 10 bytes.

To insert binary data into the table, you can use an appropriate data representation, such as hexadecimal notation. Here’s an example of inserting binary data into the table:

<code>INSERT INTO BinaryData (ID, Data)
VALUES (1, 0x5468697320697320612062656E617279);

In the example above, a row is inserted into the “BinaryData” table. The “ID” column is assigned the value 1, and the “Data” column is assigned a binary value represented in hexadecimal notation. The hexadecimal value corresponds to the ASCII representation of the string “This is a binary”.

When retrieving data from a BINARY(n) column, you will receive the binary value as stored, which you can process or interpret according to your application’s needs.

It’s important to note that the exact syntax and capabilities of BINARY(n) may vary slightly depending on the specific database system you are using, but the concept remains consistent across most SQL implementations.

The VARBINARY(n) SQL Data Type

The VARBINARY(n) data type in SQL is used to store binary data of variable length. It allows you to store binary strings with a maximum length of ‘n’ bytes. The ‘n’ value specifies the maximum storage size, and it can range from 1 to 8,000.

Here’s an example to illustrate the usage of VARBINARY(n):

Let’s say we have a table called “Images” that stores images in binary format. We want to create a column named “ImageData” to store the binary image data using the VARBINARY data type. We’ll set the maximum storage size to 1000 bytes:

<code>CREATE TABLE Images
(
    ImageID INT PRIMARY KEY,
    ImageName VARCHAR(100),
    ImageData VARBINARY(1000)
);

In this example, the “Images” table has three columns: “ImageID,” “ImageName,” and “ImageData.” The “ImageData” column is defined with the VARBINARY(1000) data type, allowing a maximum storage size of 1000 bytes for each image.

To insert a binary image into the table, you can use an INSERT statement like this:

<code>INSERT INTO Images (ImageID, ImageName, ImageData)
VALUES (1, 'example.jpg', 0xFFD8FFE000104A46494600010100000100010000FFDB004300080606070605080707070909080A0C140D0C0B0B0C1912130F141D1A1F1E1D1A1C1C20242E2720222C231C1C2837292C30313434341F27393D38323C2E333432FFDB0043010909090C0B0C180D0D1832211C2132323232323232323232323232323232323232323232323232323232323232323232323232323FFC000110800A800A8003F01FFD9000000
);

In this example, we’re inserting an image with ImageID 1, ImageName ‘example.jpg,’ and the actual binary data represented by hexadecimal values starting with ‘0x.’ The hexadecimal value is the binary representation of an image file.

When you query the table, you can retrieve the binary data and work with it as needed, such as displaying the image or performing other operations.

The VARBINARY data type is commonly used when dealing with binary data like images, documents, or encrypted data, where the length can vary from one entry to another.

Other Common SQL Data Types IN SQL

• UUID: Universally unique identifier.
• XML: Stores XML data.
• JSON: Stores JSON (JavaScript Object Notation) data.

The UUID Data Type

In SQL, a UUID (Universally Unique Identifier) data type is a 128-bit value used to uniquely identify records or entities within a database. It is often used when there is a need for globally unique identifiers that can be generated independently of the database system.

A UUID is represented as a string of 32 hexadecimal digits, typically grouped into sections separated by hyphens. The format follows a specific pattern: “xxxxxxxx-xxxx-Mxxx-Nxxx-xxxxxxxxxxxx”, where “x” represents a hexadecimal digit, “M” denotes the version of the UUID, and “N” indicates the variant.

Here’s an example of a UUID in SQL:

<code>f47ac10b-58cc-4372-a567-0e02b2c3d479

In this example, the UUID consists of five groups of hexadecimal digits separated by hyphens. Each group is of a specific length, and the overall length is 36 characters.

It’s worth noting that the specific format and structure of a UUID may vary depending on the database system you’re using. Some databases provide built-in functions to generate UUIDs, while in others, you may need to use external libraries or generate UUIDs programmatically.

The XML Data Type

In SQL, the XML data type is used to store XML (eXtensible Markup Language) data within a database column. XML is a popular format for representing structured data, and the XML data type allows you to store, retrieve, and manipulate XML documents directly within the database.

Here’s an example to illustrate how the XML data type works in SQL:

Let’s say we have a table called “Books” with the following structure:

<code>CREATE TABLE Books (
    BookID INT PRIMARY KEY,
    Title VARCHAR(100),
    Author VARCHAR(100),
    PublicationDate DATE,
    BookData XML
);

In this table, the “BookData” column is defined as an XML data type, which means it can store XML documents.

Now, let’s insert a sample XML document into the “BookData” column:

<code>INSERT INTO Books (BookID, Title, Author, PublicationDate, BookData)
VALUES (
    1,
    'The Great Gatsby',
    'F. Scott Fitzgerald',
    '1925-04-10',
    '
        <book>
            <genre>Novel</genre>
            <description>A story about the American Dream</description>
        </book>
    '
);

In the example above, we inserted an XML document representing a book into the “BookData” column. The XML document contains elements such as “genre” and “description,” which represent different properties of the book.

To retrieve the XML data from the “BookData” column, you can use SQL queries and XML functions. For instance, to retrieve the genre of the book with BookID 1, you can use the following query:

<code>SELECT BookData.value('(/book/genre)[1]', 'VARCHAR(50)') AS Genre
FROM Books
WHERE BookID = 1;

This query uses the value() method to extract the value of the “genre” element from the XML document stored in the “BookData” column. The result would be:

<code>+---------+
|  Genre  |
+---------+
|  Novel  |
+---------+

You can also perform various operations on XML data, such as querying, modifying, and transforming it using XML functions and methods provided by the database management system.

The XML data type in SQL enables you to store structured data in XML format within a database column, making it easier to manage and manipulate XML documents directly within the database environment.

The JSON Data Type in SQL

In SQL, the JSON data type is used to store and manipulate data in the JavaScript Object Notation (JSON) format. JSON is a widely used data interchange format that is human-readable and easy to parse. The JSON data type allows you to store JSON documents within a SQL database column, providing flexibility for handling structured data.

Here’s an example of how the JSON data type can be used in SQL:

Let’s say we have a table called “Employees” with the following columns:

• id (integer)
• name (string)
• details (JSON)

The details column is of JSON data type and will store additional information about each employee in JSON format.

Here’s an example of how the “Employees” table might look:

<code>+----+---------+--------------------------------------------------+
| id |  name   |                    details                       |
+----+---------+--------------------------------------------------+
|  1 | John    | {"age": 30, "department": "Marketing"}           |
|  2 | Emily   | {"age": 35, "department": "Sales", "manager": 1} |
|  3 | Michael | {"age": 40, "department": "HR", "manager": 2}    |
+----+---------+--------------------------------------------------+<span style="background-color: initial; font-family: inherit; font-size: inherit; font-weight: inherit;"></span>

In this example, the “details” column contains JSON data representing various attributes of each employee. For instance, the first row has a JSON object with keys “age” and “department”, while the second and third rows have additional keys like “manager”.

To work with JSON data in SQL, you can use specific JSON functions and operators provided by your database management system. These functions allow you to extract, manipulate, and query the JSON data within the columns.

For example, you could retrieve all employees who belong to the “Sales” department and have a manager using a query like this:

<code>SELECT * FROM Employees WHERE details->>'department' = 'Sales' AND details->>'manager' IS NOT NULL;<span style="background-color: initial; font-family: inherit; font-size: inherit; font-weight: inherit;"></span>

This query would return the second row in the table:

<code>+----+-------+--------------------------------------------------+
| id | name  |                    details                       |
+----+-------+--------------------------------------------------+
|  2 | Emily | {"age": 35, "department": "Sales", "manager": 1} |
+----+-------+--------------------------------------------------+

In summary, the JSON data type in SQL allows you to store and manipulate structured data in the JSON format, providing flexibility and ease of use when working with complex and dynamic data.

In Summary

By providing a standardized and structured approach to data representation, SQL’s data types play a crucial role in maintaining data integrity, optimizing storage, enabling data manipulation, and facilitating efficient data retrieval and presentation. Choosing the appropriate data type for each column is essential for designing robust and performant database schemas

SQL Data Types : Essential FAQs for Developers
